Timber Frame pegs – 12″
12″ wood pegs are available in Red Oak (the most common), or White Oak.
White Oak only available in Straight style.
- Straight pegs are turned approximately 1/64″ oversize
- Double chamfered pegs have a decorative 45 degree chamfer on either end…and only available in 1″
- Tapered pegs are 1/64″ over the measurement, tapered to 1/64″ under.
Image showing 3 pegs styles is as follows from left to right…Double chamfer, Straight (starter bevel one end), and Tapered.
NOTES: Due to the mechanism that holds the peg during manufacturing the 3/4″ diameter tapered pegs start with a full 1″ diameter for the first 1″ of the peg…if you cut this off (often after installing), you’ll end up with an 11″ peg.
NOTES: Many auger bits actually cut +/- .030 oversize…in part so the shaft/flites aren’t overheating with the friction of rubbing on the sides of the hole and part due to many woods appear to ‘swell’ a bit upon drilling. In effect, making the hole close to call size. Thus, it’s best to have a couple of brands of drill bits available to test against.
Looking for other lengths? Try HERE!
