Barker Tenon Cutter
Barker Tenon Cutters
- Heavy duty design.
- Made of machined high-grade aluminum in either single or double blade styles.
- Your choice of replaceable 1/2″ or 3/4″ diameter shaft. (the part that goes into your drill chuck)
Additional Notes:
- Single blade cutters take approximately 5 seconds longer to cut a tenon than double blade cutters.
- Thus, single blade cutters are easier on the drill and create less torque to the material being tenoned, which means it’s easier to secure the material
- All aluminum Barker cutters have built in levels…handy to get started level.
Tenon Diameter | Max Tenon Length | Max Wood Diameter | Shaft Size | Blades |
4″ | 3-1/2″ | 6″ | 3/4″ | 1 |
3″ | 3-1/2″ | 5-1/2″ | 3/4″ | 1 |
2-9/16″ | 3-1/2″ | 5″ | 1/2″ or 3/4″ | 1 or 2 |
2″ | 2″ | 4-1/2″ | 1/2″ or 3/4″ | 1 or 2 |
1-1/2″ | 1-1/2″ | 4″ | 1/2″ or 3/4″ | 1 or 2 |
1″ | 1-1/2″ | 3″ | 1/2″ or 3/4″ | 2 |
3/4″ | 1-1/2″ | 2-1/2″ | 1/2″ or 3/4″ | 2 |
